IEEE 14-bus modified test system

The IEEE 14-bus modified test system consists of 5 synchronous machines with IEEE type-1 exciters, 3 of which are synchronous compensators used only for reactive power support. There are 19 buses, 17 transmission lines, 8 transformers and 11 constant impedance loads. The total load demand is 259 MW and 73.5 MVAr.

Download Files

  1. IEEE 14-bus modified test system (pdfemf)
  2. PowerWorld Files (pwdpwb* Simulator 17 or newer
  3. DIgSILENT Files (pfd*  PowerFactory 15.1 or newer
