The IEEE 30-bus modified test system has 6 synchronous machines with IEEE type-1 exciters, 4 of which are synchronous compensators, 36 buses, 37 transmission lines, 10 transformers and 21 constant impedance loads. The total load demand is 283.4 MW and 126.2 MVAr.
